KR-1568

15-inch 64nm Marine Radar

Daha Fazla

Fiyat için teklif alınız

Ürün Açıklaması

Antenna Radiator

Radiator
Slotted waveguide Array
Radiator Length
120 cm
Antenna Rotation Speed
24 RPM
Wind Resistance
Relative wind speed 100 knots(51.5 m/s)
Beam Width
Horizontal 1.9°
Vertical 22°
Sidelobe
Within ± 20° off mainlobe; less than -24 dB
Outside ± 20° off mainlobe; less than -30 dB
Polarization
Horizontal



 Transceiver Module (contained in Antenna)

Transmitting Tube
MAF1422 or MSF1422
Frequency
9410 ± 30MHz (X-band)
Pulse Length PPR
0.08 µ s/2100 Hz(0.125, 0.25, 0.5, 0.75, 1.5 nm)
0.3µ s/1200 Hz(1.5, 2, 3 nm)
0.8 µ s/600 Hz(3, 4, 6, 8, 12, 16, 24, 36,48, 64, 72 nm)
Warm Up time
1:30 minutes
Peak Output Power
6 kW nominal
Modulator
FET Switching Method
IF
60MHz
Tuning
Automatic or Manual
Receiver front end
MIC (Microwave IC)
Bandwidth
Tx pulselength 0.3 µS and 0.08µS: 25 MHz
Tx pulselength 0.8µS: 3 MHz
Duplexer
Circulator with Diode Limiter



 Environment

Temperature
Display unit: -10 to +50°C
Antenna unit: -25 to +70°C
Humidity
Relative humidity 93% or less at 40°C



 Power Supply

12V, 24V or 32VDC (10.5V to 40.0 VDC) 60W (30W in economy mode)



 Display Unit

Type
15-inch LED backlight, 32-bit TFT Color LCD Display
Display Modes
Head-up, Course-up*, North-up*, True Motion**
* Heading input required
** Heading and speed inputs required
Range Scale
Range: 0.125, 0.25, 0.75, 1, 1.5, 2, 3, 4, 6, 8, 12, 16, 24, 36, 48, 64, 72
Range Interval: 0.0625,0.125,0.25,0.25,0.25,0.5,0.5,1,1,2,2,4,4,6,8,16,12
Number of Rings: 2,2,3,4,6,4,6,4,6,4,6,4,6,6,6,4,6
Bearing Resolution
Bearing Accuracy
Within 1°
Range Discrimination
Better than 30 m
Range Ring Accuracy
0.9% or range in use or 8 m whichever is larger
Minimum Range
Better than 25 m
Target Tracking Function
Acquisition : 30 manual
Tracking : Auto
Display : Speed, Course, Range/Bearing and CPA/TCPA
Vibration
Vibration Total Amplitude:
1 to 12.5 Hz± 1.6 mm
12.5 to 25 Hz± 0.38 mm
25 to 30 Hz± 0.1 mm
Echo Trail
Interval: 15s, 30s, 1min, 3mins, 6mins, 15mins, 30mins or continuous
Interface
any talker (menu selection) input
$–APB,$–BWC,$–BWR,$–DBK,$–DBS,$–DBT,$–DPT,
$–GGA,$–GLC,$–GLL,$–GTD,$–HDG,$–HDW,$–HDT,
$–MDA,$–MTW,$–RMA,$–RMB,$–RMC,$–VTG,$–VHW,$–XTE
AIS Display
Tracking : Auto
Display : Vessel Name, MMSI, Call sign, Range/Bearing, L/L
Speed/Course, ROT, CPA/TCPA
(AIS data input required)

 Equipment List

Display unit: 1 unit
Open-Array Antenna with 1.2m Scanner
ANTENNA CABLE : 10/15/20/30m (Specify when ordering)
POWER CABLE: 3m
Operation Manual
Standard Spare Parts and installation materials : 1 set
